2301/2303 Cable
|
Cable Type
|
Operating Frequency
(GHz) |
Cable diameter (inches)
|
Bending Radius (inches)
|
Weight
(lbs/100 ft)
|
VP
% |
Delay
(Ns / ft.)
|
|
2301
|
26.5
|
0.224
|
1 1/4
|
4.5
|
84
|
1.2
|
|
2303
|
26.5
|
0.290
|
1
|
8.1
|
84
|
1.2
|
|
Attenuation > 100dB TO 18 GHz
|
|||||||||||||||||
|
Connector loss:
|
Connection Type
|
||||||||||||||||
|
Straight
|
Right angle bend
|
||||||||||||||||
|
N, SMA, TNC, SC
|
0.012*F
|
0.017*F
|
|||||||||||||||
|
* 3.5mm
|
0.01*F
|
N/A
|
|||||||||||||||
|
|||||||||||||||||
|
VSWR:
|
Connection Type
|
||
|
2 Straight
|
1 Straight
|
2 Right angle bend
|
|
|
Connections
|
1 Right angle bend
|
Connections
|
|
|
18 GHz Assemblies
|
1.35
|
1.40
|
1.45
|
|
26.5 GHz Assemblies
|
1.35
|
N/A
|
N/A
|
